Victron Energy - 80V - 300A - ANL Fuse (Pack of 5)

Victron ANL Fuse 300A/80V - Pack of 5

Bolt-Down Overcurrent Protection for High-Current DC Systems

This pack contains five Victron ANL fuses rated at 300A/80V, sized for heavy DC cable runs feeding inverters, chargers and DC distribution on battery banks. The 80V rating gives Victron's ANL fuses the headroom to safely clear a fault on 12V, 24V or 48V systems without sustained arcing, well beyond what a standard 32V-rated automotive fuse can handle.

Victron's own figures for this rating are an approximate voltage drop of 125mV and a cold resistance of 0.18mΩ, keeping losses low across the fuse in normal operation. Like Victron's MIDI and MEGA fuse ranges, the ANL is a bolt-down, open-body fuse designed to fit a matching Victron ANL fuse holder.

Supplied as a pack of five, this listing gives you a set of matched spares so a blown fuse can be replaced immediately with one of the correct, identical rating.

Key Features

• 5 x 300A/80V ANL fuses, all the same rating, for spares and multi-circuit builds
• 80V DC rating suited to 12V, 24V and 48V DC battery banks
• Approx. 125mV voltage drop and 0.18mΩ cold resistance for low power loss
• Bolt-down terminals for a secure, vibration-resistant connection in a Victron ANL fuse holder

Specifications
